New for 2019 is the amazing Wave Vision window that is clear all the way to the mast. The experience of wave riding with virtually no visual restrictions makes the 2019 a dramatic change form past designs. Oddly this feature is so helpful even on flat water as jibes and any maneuver become so much easier when you do not have to look through a "window".

Last year we added the additional low clew option to improve down the line wave sailing. This allows the sail to mimic the KS3 boom angle that allows you to get up and under the lip better than the high clew position. The upper clew position is a better fit for extreme jumping and on shore sailing. Sailors who liked the Qu4d but felt the KS3 was better down the line are now totally satisfied with Qu4d in all conditions.

The Qu4d is a great choice for those who enjoy jumping as much as wave riding. This sal flies through the air with a stability and accuracy that is stunning. The shorter luff lengths and boom lengths encourage fast rotations too.

The QU4D incorporates our super light 2 and 4 mil laminates and which is combined with our new very clear SlamLam® reinforced window making this a super strong wave sail which will take a pounding while remaining very light.

Designed to rig on short masts the overall rig weight is reduced further. You will only need a 400 to rig the 6.0m through 5.2m, a 370 to rig 5.0 through 4.3 and a 340 for the smallest sizes.


Hard Core Wave
On-Shore Wave
Off-Shore Wave
Soft Wave
Light Wind

QU4D Sail Features

  • 4 battens
  • Huge new DP® Sailcloth SLAMLAM® window stays clear longer
  • 2 clew positions rigging for down the line wave riding vs. jumping.
  • 1.5mil scrim super light laminates.
  • Super Compact Shaping (SCS)
  • Three full length battens with exclusive SuperSkin® reinforcing
  • 2x3mm "mini" battens with exclusive SuperSkin® reinforcing
  • Indestructible Ox Webbing UHMWPE luff sleeve
  • "S" bend batten de-power and shape stability system
  • New easy roll sleeve top
  • DP® Sailcloth "Flex" triple laminate luff top reinforcing
  • Single position 20mm stainless steel press clew ring
  • Technora® tack and clew reinforcing
  • Boom height markings printed inside and out the boom opening
  • Genuine sailmaker's leather chafe trim
  • Foot edge raised bead for maximum deck chafe resistance
  • Removable triple pulley downhaul in 316 Stainless and bronze
  • 900kg strength UHMWPE tack pulley webbing
  • Ribbed EVA mast pad with 5cm wide hook and loop closure


Size Luff Boom Ideal Mast Battens Weight (LB) Weight (KG)
3.5 350 139 340 4 5.9 2.7
3.9 366 145 340 4 6.2 2.8
4.3 378 154 370 4 6.5 2.9
4.5 384 158 370 4 6.6 3
4.7 389 163 370 4 6.7 3
5.0 398 170 370 4 6.8 3.1
5.2 406 174 370 4 7 3.2
5.6 421 181 400 4 7.2 3.3
6.0 436 184 430 4 7.7 3.5
